CNC Automatic fabric layer cutting machine for sale

Features of automatic fabric layer cutting machine

The automatic fabric layer cutting machine  is specifically for the apparel, automotive interiors, home, bags, shoes, hats, home textiles, outdoor tents and other larger-scale production.

Our machine adopts automatic knife sharpening technology,the knife sharpening time can be controlled by different fabric, which will extend the using life of the cutting blade. With a high reuse rate,Convenient process management.

Parameter of automatic fabric layer cutting machine

technical parameters/model

AOYOO-1625-ZS6

AOYOO-1825-ZS8

Effective working area

1600x2500mm

1800x2500mm

Multi-function tool

Vibrating knife full cut, semi-cutting cut, indentation, drawing mark, cursor positioning, camera positioning edge cutting, high power active round knife

safety devices

Safety devices use infrared sensing, safe and reliable

Cutting speed

200-2000mm/s

Cutting thickness

≤50mm Other thicknesses can be customized according to the material

Applicable materials

Knitting, woven, fur (sheep shearing), PU leather, oxford cloth, canvas, sponge, imitation leather, cotton linen, blended fabric etc. All kinds of clothing, bags, sofa fabrics and carpet fabric etc

Material fixing method

Vacuum partition adsorption

Transmission port

Network port

Transmission system

The X\Y axis is divided into two kinds of rack or belt

rated power

11kw

Rated voltage

380V±10%/220V±10% Optional

Control System

Chinese and English LCD touch screen

Operating environment

Operating environment Temperature 0-40°C Humidity 20%-80%RH

Support file format

AI、PLT、DXF、PDF、 PCE、XML

Overall size

3600x2400x1200mm

3600x2600x1200mm


Advantages of automatic fabric layer cutting machine

1). Low operating costs: Thanks to the use of proven and commonly available components it is possible to quickly replace operating elements without incoming high costs.

2). It can do zero distance cutting,save more raw materials, Automatic fabric layer cutting machine,can reduce a lot of cutting workers, which can realize mass productionThe high cutting precision can improve the cutting efficiency, so sewing workers can sewing directly, no need to trim the cutting pieces The control software can support different kinds of file format,which Can direct docking clothing design and layout design, Unique algorithm and motion control technology, to realize the seamless joint between the straight line and arc, which can make the cutting much more precision.

Analysis of Benefit:

1.the image of your company, increase the competitiveness of orders.


2. Quality assurance, improving and reduce the fabric material missing during working, thus ensuring tension-free spreading.


3.Work efficiency, a spreader to work 10 hours a day basis, you can complete about 10,000 - 12,000 meters (denim), the equivalent of 4 - 6 workers Labor.


4.Saving fabrics, thereby reducing costs, improve the competitiveness of orders and bargaining chips.


5.Addition value. Make full use of the advantages of fully automated machines to enhance your staff's sense of competition, and can be effective.


Automatic fabric layer cutting machine for sale



About AOYOO:

AOYOO is your best partner, we are not only the manufacturer of machines but also solve your technical problems, we can support the technical service, we are also your technology supplier.


1). Creating value: The in-plant training program can be a valuable and beneficial service to your cutting.


2). Services Customizations: Thanks to 10 year's experience with installations throughout the World, we can offer innovative solutions for specific problems and turn-key projects.


3). AOYOO Remote Service: AOYOO Remote Service is a remote support service that provides our technical staff to connect directly to your workstation and have direct access to the desktop, like being on your location.


Click to learn more

AOYOO Patent And Certification.jpg

Machine Packaging And Logistics.jpg

AOYOO’s main products include smart blade cutting machines, which can cut flexible materials in a variety of different industries and allow auxiliary cutting tools to work together, and our staff are professional in providing solutions for various industries. Welcome to consult!
