Logo Blanket Cutting Equipment

Features of logo blanket cutting equipment

1. Elegance, comfort and details precision play a primary role in furniture.

2. Leader in cutting foam, leather and man-made materials in single or multiple layers, AOYOO is able to offer a wide range of products studied to manufacture furniture in series or design items, such as beds, sofas, chairs and more.

3. The production includes systems to acquire and modify shapes, to scan leather contour and define quality areas, to automatically position the shapes on leather and synthetic materials and further cutting.

Specification


Technical parameters / model

AOYOO-1625-ZS6

AOYOO-1825-ZS8

AOYOO-2125-ZS10

Accept unconventional model customization

Effective working area

1600x2500mm

1800x2500mm

2100X2500


Multi-head optional

Double head optional efficiency doubled, double gantry optional, double head mutual shift optional, length can be customized

Multi-function tool

Vibrating knife full cutting, high power active round knife, punching tool, pneumatic knife, multi-layer knife

safety devices

Safety devices use infrared sensing, safe and reliable

Cutting speed

200-2000mm/s

Cutting thickness

≤50mm Other thicknesses can be customized according to the material

Material fixing method

Vacuum partition adsorption

Transmission port

Network port

Transmission system

Yaskawa servo motor, linear linear guide, timing belt, lead screw

rated power

11kw

Rated voltage

380V±10%/220V±10% Optional

Control System

Chinese and English LCD touch screen

Operating environment

Operating environment Temperature 0-40°C Humidity 20%-80%RH

Software

Automatic nesting software, template entry software(Optional)

Support file format

AI、PLT、DXF、CDRetc

Overall size

3570x2290x1165mm

3570x2500x1165mm

3570x25800x1165mm


Cutting video

Application And Machine Details

car mats, foam compound, XPE, EVA, fabric carpet, imitation leather, leather, cloth etc. Applicable Industry:  Automotive interior, composite materials, seal gasket, sports goods, safa fabric etc.


Application


Machine Advantages

1.Both manual and automatic feeding available.

2.With safety device of urgent buttons and double hands working.

3.Easy to set and unload plates,simple to operate.


In order to help you find a solution for your cutting needs, we have added a list of all of the kinds of intelligent blade tool.


Machine Details

Product Advantages

FAQ:

Q1: I knew nothing about this machine, what kind of machine i should choose?

     Very easy to choose. Just tell us what you want to do by using CNC cutting machine, then let us give you perfect solutions and suggestions.

Q2: When I got this machine, but I don’t know how to use it. What should I do?

     We will send video and English manual with the machine. If you still have some doubts, we can talk by telephone or skype and e-mail.

Q3: If some problems happen to this machine during warranty period, what should I do?

    We will supply free parts during machine warranty period if machine have some problems. While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.

Q4: Before sending me an inquiry on our cutting machine, it is better for you to provide me the following information

1)Your materials.

Colth/Lesther/Fabric/Rubber/Carpet/Corrugated box/Textiles?

2)You want to engrave or cut?

If cut, could you tell me your cutting thickness? Because different cutting thickness need different blade supplier.


AOYOO Patent And Certification


Packaging advantages:

1.Whole film packaging machine

2.Anti-collision package edge

3.Wooden case package

About AOYOO

We have many agents in the world. If you are interested in becoming an agent,or if you have any questions about the products, you can leave a message and we'll make sure you receive the information you need promptly.

About AOYOO

AOYOO’s main products include smart blade cutting machines, which can cut flexible materials in a variety of different industries and allow auxiliary cutting tools to work together, and our staff are professional in providing solutions for various industries. Welcome to consult!
