Features of China KT board cutting machine:
The high precision China KT board cutting machine is designed for production with small quantities and can save on costs while maintaining speed and accuracy.
1. Ectric shock and head, strength, vibration frequency is high, up to 60000 times per minute.
2. The whole machine adopts the high precision module of the first level transmission mechanism, the response is faster, the positioning accuracy is higher, the overall performance is more stable.
3. Using Servo-motor , With computerized control, the depth of cutting and creasing can be adjusted precisely according to the need of box designer and makers.
4. Drawing lines, drawing, text annotation, half cutting, full knife cutting, a complete. Meet the low volume, multi order, multi style production target.
5. The completely independent research and development of computer control system, namely the humanized operation interface, support for remote teaching, remote maintenance, remote upgrade, let the customer with more peace of mind.
Specification of China KT board cutting machine
Technical parameters / model | AOYOO-1625-ZS6 | AOYOO-1825-ZS8 |
Effective working area | 1600x2500mm | 1800x2500mm |
Multi-function tool | Vibrating knife full cut, semi-cutting cut, indentation, drawing mark, cursor positioning, camera positioning edge cutting, high power active round knife | |
safety devices | Safety devices use infrared sensing, safe and reliable | |
Cutting speed | 200-2000mm/s | |
Cutting thickness | ≤50mm Other thicknesses can be customized according to the material | |
Applicable materials | Knitting, woven, fur (sheep shearing), PU leather, oxford cloth, canvas, sponge, imitation leather, cotton linen, blended fabric etc. All kinds of clothing, bags, sofa fabrics and carpet fabric etc | |
Material fixing method | Vacuum partition adsorption | |
Transmission port | Network port | |
Transmission system | Yaskawa servo motor, linear linear guide, timing belt, lead screw | |
rated power | 11kw | |
Rated voltage | 380V±10%/220V±10% Optional | |
Control System | Chinese and English LCD touch screen | |
Operating environment | Operating environment Temperature 0-40°C Humidity 20%-80%RH | |
Support file format | AI、PLT、DXF、CDRetc | |
Overall size | 3570x2290x1165mm | 3570x2500x1165mm |
Application And Details of China KT board cutting machine
Leather, cardboard, fiber glass,KT board,sticker,display card board,corrugated cardboard, honeycomb cardboard, sticker, film, foam board,acrylic board, rebound rubber, rubber cloth, gasket material, garment cloth, footwear material, bags materials, non-woven fabrics, carpets, sponge, PU, EVA, XPE, PVC, PP, PE, PTFE, ETFE and composites.
Pre-Sales Service
1.Inquiry and consulting support.
2.Sample testing support.
3.View our Factory.
After-Sales Service
1.Training how to install the machine, training how to use the machine.
2.Engineers available to service machinery overseas.
Warranty
Machines are new (or unused) and the guarantee period will be given thirteen months from shipment date. During this period, the seller will provide free maintenance and free spare parts that caused by the machine's quality, but the buyer must pay the courier cost. Parts damaged because of mishandling and consumable parts are not covered by any warranty.
Patent And Safety Certificate
Why Choose AOYOO?
1. Competitive price: It is can meet your budget and best-selling business very well.
2. OEM Accepted: We can produce any your request design.
3. Good Service: We treat clients as friends.
4. Good Quality: We have strict quality control system.
About AOYOO
Shandong AOYOO is one of the professional China KT board cutting machine manufacturers and suppliers in China, welcome to buy our China KT board cutting machine from Jinan and check the price with us.
