Auto ceramic fiber gasket cutting machine

The ceramic fiber gasket cutting machine uses CNC intelligent cutting system. During the cutting process, the ceramic fiber gasket is strongly absorbed and cut stably. It is suitable for cutting gaskets of different materials to ensure that your mass production is always in good condition. carry out.



chnical parametersAOYOO-1625
Effective working area1600*2500mm
Multi-function cutting headThe combination of Multi-function cutting head and holders, be with full cut, kisscut, creasing wheel,v-cut and laser red light positioning functions, CCD positioning, Camera extract large contour to cut
ToolsOscillating knife, Milling tool, pneumatic knife, V-cut, crease wheel, kiss cut, drag knife
Moving speed800-1500mm/s
Repeat precIsion±0.05mm
InterfaceEnternet port
Control panelLCD touch screen
Drive systemImported servo motor, linear guid, synchronous belt, screw
Instruction systemHP- GL Compatible format
Rated power2. 2KW
Rated voltage220V
Cutting thickness≤50mm(According to different material)
Material fixed wayVacuum adsorption
Auto feeding systemAcuum sucker adsorpting sheet



Feature of Ceramic fiber gasket cutting machine

1. A variety of blade types to achieve various special-shaped cutting, breaking through the limitations of traditional cutting technology.

2. The blade is made of imported tungsten steel, the edges are vertical and neat, and the edges are free of burrs.

3. It adopts Japanese Panasonic servo motor and Swedish rack and pinion drive to provide stable and continuous high-precision cutting, and the accuracy error is maintained at ±0.05mm.

4. The ceramic fiber gasket cutting machine obtained the world's five patented technology certifications.


Advantage of Ceramic fiber gasket cutting machine

1. The system is equipped with super typesetting software, which can customize and optimize the layout of the cutting path, saving more than 20% of materials.

2. The cutting software image adopts laser projection technology, and the edge detection and filling and cutting functions continuously improve the utilization rate of residues.

3. Unique multi-zone adsorption technology, the adsorption capacity is increased by more than five times.

4. Equipped with different types of knives, designed to cut gaskets of different soft and hard materials to ensure perfect cutting results.

detail of Ceramic fiber gasket cutting machine

Packaging of Ceramic fiber gasket cutting machine

1. Our wooden box was fumigated. No wood inspection is required, saving transportation time.

2. All parts of the machine are wrapped in soft materials, mainly using pearl cotton. Avoid all damage that may occur during delivery. Then, we wrap the plastic bag tightly to ensure that the covering soft material is intact and to avoid water and rust.

3.Warning signs are posted around the wooden box.

packaging of Ceramic fiber gasket cutting machine

Service of Ceramic fiber gasket cutting machine

1) We provide three-year warranty service, and the main components will be replaced free of charge within one year

2) Provide free technical support for life.

3) If necessary, wearable parts (such as blades, workbench covers) are always provided at the lowest price.

4) Our factory conducts free operation training. If there is not enough time, we will send detailed training videos.

5) 24-hour online service, providing free technical support in different languages.

6) Provide on-site technical support when necessary.

service of aoyoo.png

About delivery time

we have our own factory. After placing the order, we will start producing the CNC cutting machine you need. At the same time, we will make a reasonable delay based on the order volume of the month. Our delivery time is about 15-20 days on average. CNC cutting machines can also be produced according to your required delivery time. Please leave a message for specific information.





AOYOO is a CNC cutting machine brand under Jinan AOL CNC Equipment Co, Ltd. It is a leading brand in the CNC cutting machine industry, integrating design, development and manufacturing. Our machine can not only be a ceramic fiber gasket cutting machine, our CNC cutting machine is also suitable for advertising packaging industry. Composite material industry, clothing industry, carpet industry and many other industries can adapt to cutting and achieve perfect cutting results. If you are interested in CNC cutting machines, please leave a message for consultation!


AOYOO’s main products include smart blade cutting machines, which can cut flexible materials in a variety of different industries and allow auxiliary cutting tools to work together, and our staff are professional in providing solutions for various industries. Welcome to consult!
